APC Smart-UPS RT 5000VA, 230V, LCD, without kit, 2x IEC 60320 C13 & 1x IEC 60320 C19 outlets SRTG5KXLI

900,000.00

Category: Tag:

Output

Max Configurable Power (Watts)

5.0kWatts / 5.0kVA
Output Voltage Note

Configurable for 220 : 230 or 240 nominal output voltage
Output Voltage Distortion

Less than 2 %
Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz Sync to mains
Other Output Voltages

220 V, 240 V
Load Crest Factor

3 : 1
Topology

Double conversion online
Waveform type

Sine wave
Bypass

Internal bypass (automatic and manual)

Input

Input frequency

40 – 70 Hz Auto-sensing
Input voltage range for main operations

160 – 285V
Other Input Voltages

220 V, 240 V

Batteries & Runtime

Battery type

Lead-acid battery
Included Battery Modules

2
Typical recharge time

4hour(s)
Nominal Battery Voltage

+/- 96 V
Expected Battery Life (years)

3 – 5
Battery Charge Power (Watts)

239 Watts
Extendable Run Time

1
Battery Volt-Amp-Hour Capacity

960

Communications & Management

Interface Port(s)

RJ-45 Serial, Smart-Slot, USB
Control panel

LED Status display with on line : on battery, Multifunction LCD status and control console
Audible Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Emergency Power Off (EPO)

Yes

Surge Protection and Filtering

Surge energy rating

600Joules

Physical

Maximum Height

178MM, 17.78CM
Maximum Width

440MM, 44.0CM
Maximum Depth

620MM, 62.0CM
Net Weight

51.9KG
Shipping weight

59.0KG
Shipping Height

275MM, 27.5CM
Shipping Width

590MM, 59.0CM
Shipping Depth

790MM, 79.0CM

Environmental

Operating Temperature

0 – 40 °C
Operating Relative Humidity

0 – 95 (Non-condensing) %
Operating Elevation

0 – 2011.68meters
Storage Temperature

-15 – 45 °C
Storage Relative Humidity

0 – 95 (Non-condensing) %
Storage Elevation

0 – 15240meters
Audible noise at 1 meter from surface of unit

55.0dBA
Online thermal dissipation

1109.0BTU/hr
Protection Class

IP20

Conformance

Approvals

CE, EN/IEC 62040-1
Standard warranty

3 years repair or replace (excluding battery) and 2 years for battery
